日本SUMITOMO住友減速機RNYMIH-1420-EP-B-30
日本SUMITOMO住友減速機RNYMIH-1420-EP-B-30
Hyponic Gearmotor
Part No – RNYM1H-1420-YA-EP-B-30
Frequency – 60 Hz
Input Speed – 1750 RPM
Poles – 4
Output Speed – 58.3 RPM
Output Torque – 1380 in-lbs
Service Factor – 1.38
Overhung Load – 805 lbs
HP – 1.5
Frame Size – 1420
Selection AGMA Class – A
Ratio – 30
Brake -YES
Sumitomo’s patented, all steel hypoid gear technology leads the industry in quiet operation and high efficiency. The Hyponic significantly outperforms worm gearing across ratios from 30:1 to 1440:1
Reduction – Combination of hypoid gear input and involute gear output.
Lubrication – Grease lubricated; filled with special high-grade grease prior to shipment.
Seals – Nitrile material, triple or double lipped output seals. Input seals are FKH.
Material – Casing: aluminum alloy or cast iron; Gear : chrome-molybdenum steel
Paint Color – Blue, Munsell color number 6.5PB 3.6/8.2 or silver
Bearings – Deep groove ball bearings on input and output.
Up to 85% efficient across all ratios and requires no cooling fan
NSF 51 approved antimicrobial powder coating
More torque density in a compact unit
Maintenance-free grease lubrication eliminates oil changes
Aluminum, corrosion resistant housing
Multiple mounting configurations
Hollow bore makes installation and retrofit quick and easy
Extremely quiet, smooth operation is ideal for commercial use
Optional popular keyed-hollow bore sizes available: 1-3/16″, 1-7/16″, 1-15/16″ 2-3/16″
? Output Shafts Available
? Stainless Steel Gear Motors Available
? Wash Down Duty Gear Motors Available
? Gear Motors with Brake Available
