德國SchottAG光纖光源kl1600LED/kl1500LED
德國SchottAG光纖光源kl1600LED/kl1500LED
Schott KL 1600 LED light source for fiber optics
The KL 1600 LED is an innovative fiber optic light source which uses cold light to illuminate all types of objects in industrial and life science applications.
SCHOTT has developed and designed a multiple LED driven light source to provide an attractive alternative to conventional halogen cold light sources. The brightness is equivalent to a 150-watt halogen lamp and therefore ideal as a powerful illumination system for the requirements of all modern stereo microscopes.
Due to its slim design, the KL 1600 LED can be placed close to microscope stand or pillar. The dimming control is than ergonomically placed to the microscope. As the chosen LEDs have a long lifetime of at least 50,000 hours it is maintenance free for the user and avoids service and downtime costs. The ripple free illumination is perfect for digital imaging applications and the color temperature of 5,600 K of the emitted neutral white light does not change when the light source is dimmend.
The KL 1600 LED combines all advantages of LED light with illumination through fiber optics: All different types of light guides of the KL 1500 series can be connected to the KL 1600 LED. This allows the full flexibility to realize all common illumination techniques. Like all KL light sources the KL 1600 LED is designed for a wide range of power supply (100-240 V; 50-60 Hz). It has been approved and certified as laboratory equipment and is in compliance with the CE regulations.
Advantages
significantly higher light intensities can be focused to a very small field of view
compact housing with small footprint
brightness is equivalent to a 150-watt halogen cold light source
extremely long lifetime of at least 50,000 hours
80% lower energy consumption
reduction of costs of ownership as well as of downtime costs
all kinds of light guides of the KL 1500 series can be connected to the KL 1600 LED
Features
Multiple-chip white LED light engine
Continuous dimming from 0 to 100%
Compact high quality housing with integrated handle
Small footprint and additional iron ballast for stability when use with goosenecks
Filter slider with two positions (filter can remain in the light source even if it is not used)
Easy to use fixture mechanism with clamping screw
Comprehensive range of light guides and accessories available (KL 1500 series)
Ultra low noise fan for ergonomic use in the laboratory
Ripple free DC illumination
General Data
Part number 150 600
Dimensions (WxDxH) 114 x 231 x 137 / 4.5" x 9.1" x 5.4"
Weight Approx. 2.45
Cooling Ultra low noise fan
Electrical data
Operating voltage, frequency 100 - 240 V ? , 50 - 60 Hz
Input voltage 24 V
Power consumption Max. 37
Average LED life time > 50,0001
Illumination data
Luminous flux Approx. 6802
Color temperature Approx. 5,600
Active light guide diameter Max. 9
Certification marks
Marking / Approval CE (power supply: CE, UL, PSE)
EMC-class B
