日本Takachi防水連接器固定座6000302CC
發布時間：2025-01-17
日本Takachi防水連接器固定座6000302CC
THB390/400 Series Circular Connector
Waterproof, T-Splitter, Relay
Part Number: THB400-6P-13
[Features]
· A waterproof connector that is connected by a screw for making work easier.
· Choose from six types of terminals, without terminal blocks: 3P, 4P, 6P, 2WP, 3WP.
· For the terminals without terminal blocks, please use protection for connectors, etc.
· These can support various cable diameters by using the optional rubber bushings (not available for some products).
Configured Specifications
| Connector Shape | Circular Type | Connector Series Initial | S/T/U |
|---|---|---|---|
| Series Initials S/T/U | [Others] THB399Y | Compatible Pin/Contact | Others |
| Number of Cores | 6 | Application | Cable Connection |
| Allowable Current(A) | 24 | Allowable Voltage(V) | AC450 |
| Wire Connection Method | Screw | Connection Direction | Straight |
| IP Rating | Present | Representative Standard | CE |
| Product Name | Waterproof Relay Connector | Conforming cable external shape (Φ)(mm) | 7 to 13.5 |
| Terminal block | 6P | Protection grade | IP68 equivalent |
| RoHS | 10 |
