日本SANYO山洋步進電機103H7123-0440
發布時間：2024-12-23
日本SANYO山洋步進電機103H7123-0440
日本SANYO山洋步進電機103H7123-0440
2-Phase Stepping Motor SANMOTION F2
103H7123-0440
Specifications
Model No.
103H7123-0440
Basic step angle [ o ]
1.8
Motor flange size[mm]
□56
Motor length [mm]
53.8
Single/Dual shaft
Single shaft
Output shaft
Circular
Holding torque [N?m]
0.83
Rotor inertia [×10-4kg·m2]
0.21
Rated current [A/phase]
2
Wiring
Unipolar
Connection type
Lead wire type
Motor mass [kg]
0.65
Operating temperature range
-10 ～ +50℃
Operating humidity range
20 to 90% RH (non-condensing)
Download Materials List
Materials Material No. File Size Download Link CAD 103H7123-0440 1.1 MB
