日本KYOWA共和網絡數據采集器NTB-100B-120
Description
NTB-100/200 Series, Network Terminal Box
The NTB-100/200 Series is a data logger, which digitizes data from the sensor and can be decentralized arrangement.
A single unit measures 4 channels, and allows up to 99 units to be connected, so measurement up to 396 channels is possible.
NTB-100B-120, Constant-voltage, one-touch terminal, 120 Ω,
Channels: 4
Measuring Target: Strain gages, strain-gage transducers
Quarter bridge 120 Ω
Half-bridge 120 to 1000 Ω Active-active system
Full bridge 120 to 1000 Ω Full bridge
NTB-100B-350, Constant-voltage, one-touch terminal, 350 Ω
Channels: 4
Measuring Target: Strain gages, strain-gage transducers
Quarter bridge 350 Ω
Half-bridge 120 to 1000 Ω Active-active system
Full bridge 120 to 1000 Ω Full bridge
NTB-101A-120, Constant-voltage screw soldering terminal, 120 Ω
Channels: 4
Measuring Target: Strain gages, strain-gage transducers
Quarter bridge 120 Ω
Half-bridge 120 to 1000 Ω Active-active system
Full bridge 120 to 1000 Ω Full bridge
NTB-101A-350, Constant-voltage screw soldering terminal, 350 Ω
Cannels: 4
Measuring Target: Strain gages, strain-gage transducers
Quarter bridge 350 Ω
Half-bridge 120 to 1000 Ω Active-active system
Full bridge 120 to 1000 Ω Full bridge
NTB-110B-350, Constant-current, one-touch terminal
Channels: 4
Measuring Target: Civil engineering transducers
Full bridge 350 Ω Full bridge
Full bridge 350 Ω Civil engineering transducer with thermal sensors
NTB-111A-350, Constant-current, screw soldering terminal
Channels: 4
Measuring Target: Civil engineering transducers
Full bridge 350 Ω Full bridge
Full bridge 350 Ω Civil engineering transducer with thermal sensors
NTB-201A, DC Voltage-output, thermocouples
Channels: 4
Measuring Target: DC voltage-output, thermocouples
Voltage-Output Measurement: [Range 10 V]
Measuring range: 0 to ±10.0000 V
Resolution: 100 μV
Thermocouples:
Type K: Measuring range: -200.0 to 1230.0°C
Type T: Measuring range: -200.0 to 400.0°C
Type E: Measuring range: -200.0 to 660.0°C
Type J: Measuring range: -200.0 to 870.0°C
Type R: Measuring range: 0.0 to 1760.0°C
Type N: Measuring range: -200.0 to 1300.0°C
NTB-20A, NTB power supply box
Power Save Function (AUTO Mode): When the PC power supply is OFF, then the power supply of the NTB-20 connected by a USB cable is off.
NTB-21A, NTB relay box
Power Supply Output Limitation Function: When power supply exceeding the range is input into NTB, the power supply output from the serial connector is turned to OFF.
NTB-10A, Network terminal box control software
